Vulcan 7

SKU: 000-14082-001

The B&G Vulcan 7 is a great value, sailing chartplotter designed for coastal cruising and club racing. This easy-to-use, intuitive 7-inch multi-touch screen is packed with B&G’s unique sailing features including SailSteer and RacePanel. Simply integrate with your existing system, expansion is simple as Vulcan is NMEA 2000®, Broadband Radar™, ForwardScan™ and autopilot ready; and features built-in 10Hz GPS and Wi-Fi.

View Key Features View Specifications

Screen Size

7" 9"

Map Bundle Option

C-MAP® DISCOVER™ Preloaded Basemap

Radar Bundle Option

None HALO20

$769

Find a dealer

-

B&G's Vulcan range of sailing chartplotters take the guesswork out of sailing. Whether you’re an experienced sailor or just starting out, Vulcan is packed with features that will help you get the most from your time on the water.

We’ve designed our Vulcan chartplotters to be as intuitive as a tablet or smartphone. The low-profile, super-bright display is visible even in direct sunlight, and the responsive touch screen gives fingertip control, even in flying spray and a rough sea state. Pinch-to-zoom, swipe and tap controls let you input waypoints and routes and view chart details with ease.

Let Vulcan guide you safely to your destination: place waypoints and routes with a single tap on the chart and let Vulcan take you there with clear, intuitive graphics and data for guidance. Add a compatible chart card to benefit from autorouting and let Vulcan’s intelligent software choose the best and safest route to your destination.

Dedicated Sailing Features for cruising and racing

You can use Vulcan as a simple chartplotter as soon as you connect it to power, or for more advanced features, add to speed, depth and wind instruments. Let Vulcan take care of the complex calculations – leaving you free to relax and enjoy the sailing.

SailSteer

See all the data you need at a glance on one easy-to-read display with SailSteer. See crucial wind, speed, tide, heading, course over ground, layline and waypoint information, overlaid on one screen to ensure you have the information you need at your fingertips.

Laylines

Let Vulcan do the hard work: See your course and minimise your time spent beating with Laylines overlaid on your chart. See which way is best and ensure you tack in the right place to help you get to windward as efficiently as possible. Laylines even take into account tidal effects and wind shifts to plot the quickest course to the next waypoint.

Navionics Chart with SailSteer page_EMEA.jpg_11716.jpg

SailingTime

Plan effectively with SailingTime and know how long it will take to get to a waypoint, even if it’s dead upwind. SailingTime calculates the time you’ll spend on each tack, taking into account wind and tidal effects, to give you an accurate ETA at your destination.

RacePanel

Be on the line when the gun goes with RacePanel. Enjoy easy-to-use features previously only enjoyed by Pro navigators to ensure you get the best start in the fleet, with time, distance and positioning information on a single clear display.

Enjoy safe and precise navigation with a Vulcan sailing chartplotter and C-MAP DISCOVER charts on your sailboat. Offering ultra-wide coverage for the US and Canada, C-MAP DISCOVER charts include full-featured Vector Charts, Custom Depth Shading, Tides & Currents and the very best of C-MAP high-resolution Bathymetric contours, including integrated Genesis® data. Planning a day on the water is simple with C-MAP Easy Routing™ and always have the latest DISCOVER chart data with 12 months of free online updates. If you would rather select your own chart, Vulcan is compatible with C-MAP, Navionics®, NV Digital and more.

Put Vulcan at the heart of your boat and take control of your B&G autopilot from your Vulcan’s touchscreen. With an installed controller elsewhere, the intuitive controls can be accessed from any screen with a simple tap and allow you to alter course, tack, gybe, sail to wind or compass. Take advantage of the advanced sailing algorithms that make B&G Pilots as good as the best helmsman – all from your Vulcan’s touch screen.

Get up and running quickly: Vulcan chartplotters are optimised for sleek flush mounting, standing only 8mm proud of the bulkhead for a low-profile ‘glass helm’ look. Alternatively, mount in minutes using the supplied bracket on horizontal, vertical or overhead surfaces.

Easy to expand your network

Expand the functionality of your Vulcan by adding onboard instruments, radar and sonar.

Instruments

Add Vulcan to Triton2 instruments and sensors to enable Vulcan's advanced sailing features and share navigation information

ForwardScan

Navigate into shallow anchorages and poorly charted areas with ease and know what lies ahead with confidence by adding a ForwardScan transducer, for a real-time two-dimensional view of the seabed in front of your boat.

SonicHub

Take control of your music and entertainment from your Vulcan display by adding a SonicHub2. With integrated Bluetooth, stream music from your smartphone or tablet, or listen to music on a USB drive or AM/FM radio.

Radar

Add our award-winning Broadband Radar to guide you through crowded harbours, poor visibility and across busy shipping lanes, or to keep an eye on distant weather and rain when sailing offshore.

We have designed Vulcan to be at home on the water and to stand up to the worst the elements can throw at it – which is why we back our products with an industry-leading two year warranty to give you peace of mind.

Key Features

Easy to use multi-touch display
Dedicated sailing features for cruising or racing: SailSteer, SailingTime, RacePanel, Laylines
Easy to integrate – Connect Vulcan to an existing system and add basic sailing components
Broadband Radar™ and ForwardScan™ ready
Integrated Wi-Fi
Control your B&G Pilot
Instrument data display

Vulcan 7R Sun Cover
B&G Zeus S Bracket
GO7 XSR / Vulcan 7R Dash Mount Kit
GO7 XSR/Vulcan 7R Bezel

Specifications

Display
Backlight Color: White
Display Resolution: 800x480
Display Size: 7 inches
Screen Brightness: 1200 nits
Viewing Angles: 80° top/bottom, 80° left/right
Connectivity
Bluetooth: Internal
Ethernet Ports: 1 x 5 pin yellow connector x 100 Mbits/s. Radar and Sirius (USA only) connectivity only
Connectivity Wi Fi: Internal
N2K PG Ns: Receive only59392 ISO Acknowledgement, 59904 ISO Request, 60928 ISO Address Claim, 65285 Temperature with Instance, 65323 Data User Group Request, 65325 Reprogram Status, 65341 Autopilot Mode, 65480 Autopilot Mode, 127245 Rudder, 127251 Rate of Turn, 127257 Attitude, 127488 Engine Parameters, Rapid Update, 127489 Engine Parameters, Dynamic, 127493 Transmission Parameters, Dynamic, 127503 AC input status, 127504 AC Output Status, 127505 Fluid Level, 127506 DC Detailed Status, 127507 Charger Status, 127508 Battery Status, 127509 Inverter Status, 129033 Time & Date, 129038 AIS Class A Position Report, 129039 AIS Class B Position Report, 129040 AIS Class B Extended Position Report, 129794 AIS Class A Static and Voyage Related Data, 129801 AIS Addressed Safety Related Message, 129802 AIS Safety Related Broadcast Message, 129808 DSC Call Information, 129809 AIS Class B “CS” Static Data Report, Part A, 129810 AIS Class B “CS” Static Data Report, Part B, 130313 Humidity, 130314 Actual Pressure, 130576 Small Craft Status, 130842 SimNet DSC Message, 130851 Event Reply, 130817 Product Info, 130820 Reprogram Status, 130832 Fuel Used - High Resolution, 130834 Engine and Tank Configuration, 130838 Fluid Level Warning, 130843 Sonar Status, Frequency and DSP Voltage,Transmit and Receive:61184 Parameter Request/Command, 65289 Trim Tab Insect Configuration, 65291 Backlight Control, 65292 Clear Fluid Level Warnings, 65293 LGC-2000 Configuration, 126208 ISO Command Group Function, 126992 System Time, 126996 Product Info, 127237 Heading/Track Control, 127250 Vessel Heading, 127258 Magnetic Variation, 128259 Speed, Water referenced, 128267 Water Depth, 128275 Distance Log, 129025 Position, Rapid Update, 129026 COG & SOG, Rapid Update, 129029 GNSS Position Data, 129283 Cross Track Error, 129284 Navigation Data, 129539 GNSS DOPs, 129540 GNSS Sats in View, 130074 Route and WP Service - WP List - WP Name & Position, 130306 Wind Data, 130310 Environmental Parameters, 130311 Environmental Parameters, 130312 Temperature, 130577 Direction Data, 130840 Data User Group Configuration, 130845 Parameter Handle, 130850 Event Command, 130831 Suzuki Engine and Storage Device Config, 130835 SetEngineAndTankConfiguration, 130839 Pressure Insect ConfigurationTransmit only65287 Configure Temperature INSOcts, 65290 Paddle Wheel Speed Configuration, 129285 Route/Waypoint Data, 130818 Reprogram Data, 130819 Request Reprogram, 130828 Set Serial Number, 130836 Fluid Level Insect Configuration, 130837 Fuel Flow Turbine Configuration
NMEA 0183 Sentences supported: Exports NMEA0183 over WiFi
NMEA 2000 Connectivity: 1 x NMEA 2000 Micro-C port, 1 LEN
PC Connectivity: None
SD Card Storage: 1 Micro SD slot, max. 32GB each. >32 GB format to NTFS
Video: None
Cartography
Charts Supported: Insight, Navionics (Gold, NAV+, Platinum+) , C-MAP (MAX N, MAX N+) NV Digital (Raster US Charts)
Autopilot
Manouevres Turn Patterns: Tack / Gybe, Depth contour tracking
Steering Modes: Wind*, Auto, Nav., No Drift, Follow up, Non-follow up, Standby, Wind NAV.* (*Boat type set to Sail)
Approvals
Approvals Compliance: CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1
Electrical
Power Consumption max: 20 W
Power Consumption typical: 12 W
Recommended Fuse Rating: 3A
Supply Voltage: 12V (10 – 17V)
Environment
Operating Temperature Range: "-15°C to +55°C (5° F to 131° F)
Shock Vibration: CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1
Storage Temperature Range: "-20°C to +60°C (4°F to 140°F)
Waterproofrating: IPX6 & 7
GPS
Correction: WASS, MSAS, EGNOS, GLONASS
GPS Receiver Channels: 32 Channels
Position Accuracy: Horizontal Accuracy 3 m (9.8 ft.)
Time to First Fix: Cold start less than 90 seconds exposed to open sky, Satellite Reacquisition 5 sec
Update rate: 10 Hz
MFD
AIS: Receive AIS data over NMEA 2000 only
Autopilot: Wind*, Auto, Nav., No Drift, Follow up, Non-follow up, Standby, Wind NAV.* (*Boat type set to Sail). Requires STBY button or Controller with STBY button to commission
Cartography included: TBD
Digital Switching: BEP C-Zone, NaviOP
GPS: Internal, 10Hz, WASS, MSAS, EGNOS
Internal Storage: 90MB
Multimedia: via SonicHub2, Fusion Link, *Sirius, **JL Audio. (*USA only, **AUST. & NZ only)
Sonar Compatibility: Integrated CHIRP / DownScan / ForwardScan. Single 9 Pin Xsonic Connector
Waypoints, Routes, Tracks: 6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points.
Weather: Sirius XM WM-3 (USA only), GRIB
Physical
Dimensions W x H x D: 197 mm x 141 mm x 82.7 mm (7.56" x 5.55" x 3.26") (no bracket)
Mounting Type: Bracket or Panel
Weight: 1.320 kg (2.91lb)
Other
Interface: Touch screen, ZC1 or ZC2 controller via NMEA 2003
Languages: Standard Language Pack: English (US), English (UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Swedish. Other Language unlocks: Asian Language Pack: English (US), Japanese, Korean, Thai, Chinese. Eastern European Language Pack: English (US), English (UK), Bulgarian, German, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Lithuanian, Latvian, Polish, Slovak, Turkish. Russia/Ukraine Language pack: English (US), English(UK), German, Spanish, French, Italian, Russian, Ukrainian. Middle Eastern Language Pack: English (US), English (UK), Arabic, German, Spanish, Farsi, French, Italian
Warranty Period: 2 Years
